The Single Shaft Plastic Head Material Shredder produced by YOUXIN plastic machinery is an essential basic equipment in the recycling and processing of waste plastics. A high-quality plastic shredder has high production efficiency, long service life, simple maintenance, low maintenance frequency, can save a lot of manpower and material resources, and generate higher economic benefits. The dual shaft plastic die material can help to recycle many kinds of plastic wastes, such as thick-walled plastic pipe, plastic lump, plastic block, plastic head material, plastic die material, plastic appliance shell, plastic film and so on.
Introduction of
Single Shaft Plastic Head Material Shredder
Single Shaft Plastic Head Material Shredder is an essential basic equipment in waste plastic recycling industry, which is specifically designed for shearing the unprocessed raw materials, plastic waste, plastic die materials, plastic injection head materials, plastic lumps, plastic blocks and heavy materials, making them being smaller pieces. It is widely used in area of waste plastic recycling, plastic process, plastic reusing and plastic injection.
| Single Shaft Plastic Head Material Shredder | |
| Model | 800 /1000 /1300 |
| Motor Power | 37KW/ 55KW /75KW |
| Hydraulic motor | 5.5KW/5.5KW /7.5KW |
| Qty of rotating blades | 48PCS/60pcs/72pcs |
| Qty of fixed blades | 4PCS/4pcs/4pcs |
| Shaft Length | 800mm/1000mm/1300mm |
Our Single Shaft Plastic Head Material Shredder is one of the most important equipment in waste plastic recycling process, which introduces a number of shredder features to aid plastic shredding performance, by design, including versatile cutting configurations for varied applications, low wear parts to minimise whole life costs, easy maintenance regimes for maximum uptime, and quick-change screens for defined fraction sizing.
Plastic shredder machine for post-consumer plastic waste is used to recycle plastic, Suitable raw materials:
1. All kinds of plastic lump: PP lumps, PE lumps, PVC lumps, plastic head materials, plastic die materials.
2. 2.Pipe material: large pipe, pipe fitting and PE pipe.
3.Plastic pallets,plastic trays,plastic sheets,plastic plates.
01 Motor
Pure copper motor output stability efficiency is higher.
02 Electronic cabinet
The equipment adopts electrical components DELIXI.
03 Gearbox
Hardened helical gear reducer.
04 Screen
Customized high-quality and stable screen can be customized screen aperture.
05 Hydraulic slider
Hydraulically driven ram to push the materials.
06 Hydraulic pump
Oil cylinder with water cooler.
07 Shaft
The spindle rotor adopts high-strength steel structure with a unique shape design.
We have advanced CNC machine center,testing equipment, and professional technician team to ensure the quality of our Plastic crusher.
OEM and ODM are available.
In order to better give you professional answers, when sending the inquiry, please describe your parameters or technical requirements (such as: processing materials, output size, capacity, etc.) and attach your contact information (such as phone number, e-mail, Facebook, WhatsApp , WeChat, etc.)
